Waste Water Pillow Tank
The Waste Water Pillow Tank is a sealed, flexible storage solution designed for the safe containment of waste water, sewage, faecal matter and industrial liquids.
Developed within the Waterbase W product line, it enables rapid deployment of sanitary infrastructure for temporary installations such as container bases, modular buildings and mobile housing. Constructed from multi-layer technical fabric resistant to hydrolysis and diluted chemicals, the tank is protected with a UV-resistant lacquer for long-term outdoor durability. Its fully flexible design requires no permanent ground anchoring and can be installed on prepared surfaces such as grass, concrete or sand.
The tank can be deployed in up to 30 minutes, while its lightweight, foldable construction ensures easy transport and relocation. High-frequency (HF) welded joints provide reliable tightness, supported by a 7-year leak-tightness warranty.
- Pictures
- Technical specification
Specification Value Product Line Waterbase W Tank Type Closed, flexible pillow tank Application Storage of waste water, sewage and industrial liquids Installation Surface Grass, concrete slabs, sand bedding Ground Anchorage Not required Assembly Time Up to 30 minutes Main Material Multi-layer technical fabric Chemical Resistance Resistant to hydrolysis and diluted mixtures UV Protection Special protective lacquer Low Temperature Resistance Down to -30°C Joint Technology High-frequency (HF) welding Warranty 7 years (leak tightness) Country of Manufacture Poland Custom Sizes Available on request Component Specification Filling / discharge connections 2 × DN80 with 3" BSP female thread, with valve Vent 2", 1 pc Handles Integrated in bottom and corners for installation and handling Additional discharge (≥75 m³) Extra outlet located on opposite short side Standard Equipment
- Downloads
