Reveal ShieldPRO
Durable, handheld thermal cameras
built for the field.
HIGH-RESOLUTION THERMAL IMAGING FOR LAW ENFORCEMENT
Introducing Reveal ShieldPRO, our newest high-resolution thermal imaging camera built exclusively for law enforcement professionals. Unlike night vision cameras, thermal imaging cameras require no ambient light and retain their clarity in any lighting condition. By helping officers quickly and efficiently clear a dark room or track a suspect, thermal cameras create an improved level of personal safety and situational awareness. Additional benefits include the ability to better investigate crime scenes, conduct search & rescue operations, and recover discarded evidence.
- Pictures
- Videos
- Technical specification
Thermal Sensor
320 x 240 (76,800 pixels) Detection Distance Long Range Detection Field of View
24 Degree FOV Frame Rate
9 Hz or 30 Hz Zoom 4x Digital Zoom IP Rating
IP67 Waterproof Display 2.4” Color with Corning® Gorilla® GlassUn cooled Microbolometer
Vanadium Oxide Startup Time 2-3 Seconds Spectral Range
7.5 - 14 Microns User Interface
Self-Contained Device with 3 Button Navigation Detecion Temp
-40 to 626F (-40 to 330C) Storage Temp
-40 to 140F (-40 to 60C) Operating Temp -40 to 120F (-40 to 50C) Runtime Up to 3.5 Hours Thermal Imaging Battery Rechargeable Lithium Battery
